ASE broadband light source 1528nm~1563nm C-Band 10mW~100mW fiber laser Advanced Desktop type

Gain flattened fiber ASE broadband light source is based on ordinary broadband light source and added the gain flattening technologies, nd optimize the structure of the light source, the output spectral flatness of <2dB, output power and high. Suitable for optical fiber sensing applications.



[Especificaciones]

Parameter Unit Typical value Remarks
Working wavelength nm 1528～1563 C-Band
Output Power mW 10mW~100mW Choose
Potencia de salida ajustable   Adjustment range
10%~100%		 Choose
1. Not Include(Fixed output power)
2.Include(Adjustable output power)
Output isolation dBm  >35
Spectral flatness dB 1.5 (Type), 2(Max)
Short-term stability (15 minutes) dB ≤ ±0.02
Long-term stability (8 hours) dB ≤ ±0.05
Fiber type   Single Mode Fiber SMF-28e
Fiber Optic Output Type   FC/APC (Default) Accept custom
Operating temperature °C -20°C ～ 65°C
Storage temperature °C -40°C ～ 85°C
Size   LCD Desktop type
260(W)×280(D)×120(H)
Power supply   AC 110V~220V
Control method   Button
Communication interface   DB9 Female(RS232) Default not include, Only for output power adjustable model.
Add software control functions, please contact us.
